All in one PC and TV for hotel
System specification
|
Display features |
|
32″ |
42″ |
|
Screen |
LED backlight |
LED backlight | |
|
resolution |
1920*1080 |
1920*1080 | |
|
Aspect ratio |
16:9 |
16:9 | |
|
Viewing angle＞ |
178 |
178 | |
|
Brightness（CD/㎡）＞ |
700 CD/㎡ |
700 CD/㎡ | |
|
Contrast |
800:1 |
800:1 | |
|
MTBF（hrs）＞ |
50000hrs |
50000hrs | |
|
Respone time＞ |
5MS |
5MS | |
|
physical |
dimetion |
CM |
CM |
|
weight |
KG |
KG | |
|
Power source |
consumption |
110W（PC＋TV） |
150W（PC＋TV） |
|
Power supply |
100~240V.50/60HZ |
100~240V.50/60HZ | |
|
TV features |
Video |
PAL/NTSC/SECAM available | |
|
TV tuning system |
Auto tuning system | ||
|
PIP |
N/A | ||
|
COM port control |
Connect the PC COM port,through the COM port to send the IR code or command complete on TV state control：1.switch on VGA,S-VIDEO,TV . 2.download TV channel information then clone to another TV from driver board’s COM port。 |
Connect the PC COM port,through the COM port to send the IR code or command complete on TV state control：1.switch on VGA,S-VIDEO,TV . 2.download TV channel information then clone to another TV from driver board’s COM port。 | |
|
Cable TV |
Full channel、including additional channel |
Full channel、including additional channel | |
|
Audio system |
4W or 5W speaker | ||
|
Video playing |
format |
VCD、DVD、MPEG-2、MPEG-1、DIVX |
VCD、DVD、MPEG-2、MPEG-1、DIVX |
|
function |
Auto power on no more than 8s 、auto playing |
Auto power on no more than 8s 、auto playing | |
|
M/B |
chipset |
Intel® NM10 |
Intel® NM10 |
|
Support OS |
WINDOW XP/7 |
WINDOW XP/7 | |
|
Resolution |
1920*1080 |
1920*1080 | |
|
RAM |
DDR3 2G |
DDR3 2G | |
|
CPU |
D2500/D2550 |
D2500/D2550 | |
|
MTBF |
MTBF>100000 hrs |
MTBF>100000 hrs | |
|
Eerthnet |
LAN port |
Dual LAN port | |
|
USB port |
internal USB*4 |
External USB*4,
internal USB*4 | |
|
Bezel |
|
armoured glass | |
|
body |
ABS |
|
|
|
Back cover |
aluminium alloy sheet
|
Support Wall-mounting | |
|
ABS engineering plastic |
Support power on card reader | ||
|
Remote contoller |
IR control |
Switch to TV or PC or S-video model and is used like PC Mouse | |
|
Mouse/KB |
Wireless Mouse/KB(optiona) |
2.4GHZ wireless，support external wireless mouse and KB | |
|
accessory
|
installation |
Desk-base or wall-mounting bracket for select | |
